injection tooling (molded PC material)

• Hot Runner System: (HUSKY), responsible for precisely delivering molten plastic to the mold cavity, is a core flow component in injection molding.
• Mold Core: (LKM)
• Waterway Connector and ejectors: DME (Metric)
• Cavity and Core: 1.2344 (HRC48-52)
• Part matreial: PC (cavity: 100℃/ core: 85℃)
• Cycle time : 55 seconds, fully automatic, capable of matching with the mechanical arm to pick up products
• Tooling Life: 300,000

injection tooling (molded Cola cup / PP material)

• Hot Runner System: (YUDO),
• Mold Core: (LKM)
• Waterway Connector and ejectors: HASCO
• Cavity and Core: S136 (HRC48-52)
• Part matreial: PP
• Cycle time : 29 seconds, fully automatic(air-ejector), capable of matching with the mechanical arm to pick up products
• Tooling Life: 500,000

injection tooling (molded PC(70%)+ABS(30%))

• Hot Runner System: (YUDO),
• Mold Core: (LKM)
• Waterway Connector and ejectors: HASCO
• Cavity and Core: S136 (HRC48-52)
• Part matreial: PC(70%)+ABS(30%)
• Cycle time : 40 seconds, capable of matching with the mechanical arm to pick up products
• Tooling Life: 200,000

injection tooling (PPS+40%GF)

• Hot Runner System: (YUDO),
• Mold Core: (LKM)
• Waterway Connector and ejectors: China
• Cavity and Core: S136 (HRC48-52)
• Part matreial: PPS+40%GF
• Cycle time : 50 seconds, capable of matching with the mechanical arm to pick up products
• Tooling Life: 100,000

injection tooling (molded PP material )

• Hot Runner System: (YUDO),
• Mold Core: (LKM)
• Waterway Connector and ejectors: HASCO
• Cavity and Core: S136 (HRC48-52)
• Part matreial: PP
• Cycle time : 25 seconds, fully automatic(air-ejector), capable of matching with the mechanical arm to pick up products
• Tooling Life: 100,000

injection tooling (molded PP+EPDM-T20)

• Hot Runner System: (YUDO),
• Mold Core: (LKM)
• Waterway Connector and ejectors: HASCO
• Cavity and Core: 1.2344 (HRC48-52)
• Part matreial: PP+EPDM-T20
• Cycle time : 29 seconds, fully automatic(air-ejector), capable of matching with the mechanical arm to pick up products
• Tooling Life: 300,000
